Traffic Rules Violation Detection System

TL;DR

This is software for the practice of developing a system from completely scratch. Understanding this will help a lot in system development and the basic structure of a system along with computer vision, GUI with python library PyQt, and basic OpenCV.

Go here if you don’t have time.

Table of content

• TL;DR
• Motivation
• Introduction
• Objective
• Quick Starting the project
• System Overview
• Methodology
  • Image Processing
  • Vehicle Classification
  • Violation Detection
  • Database Structure
• Implementation
  • Image Processing and Computer Vision
  • Graphical User Interface
  • Rules Violation Video Representation
• Contributing
• Links and References
• Author
• Licensing

Motivation

This project is made for the third year second semester System Development(CSE-3200) course.

Introduction

The increasing number of cars in cities can cause a high volume of traffic and implies that traffic violations become more critical nowadays in Bangladesh and also around the world. This causes severe destruction of property and more accidents that may endanger the lives of the people. To solve the alarming problem and prevent such unfathomable consequences, traffic violation detection systems are needed. For which the system enforces proper traffic regulations at all times, and apprehends those who do not comply. A traffic violation detection system must be realized in real time as the authorities track the roads all the time. Hence, traffic enforcers will not only be at ease in implementing safe roads accurately but also efficiently; as the traffic detection system detects violations faster than humans. This system can detect the most common three types of traffic violations in real-time which are signal violations, parking violations, and wrong direction violations. A user-friendly graphical interface is associated with the system to make it simple for the user to operate the system, monitor traffic, and take action against the violations of traffic rules.

Objective

The goal of the project is to automate the traffic rules violation detection system and make it easy for the traffic police department to monitor the traffic and take action against the violated vehicle owner in a fast and efficient way. Detecting and tracking the vehicle and its activities accurately is the main priority of the system.

Quick starting the project

1. git clone https://github.com/sakibreza/Traffic-Rules-Violation-Detection-System.git
2. Create a virtual environment using the command virtualenv venv --python=python3
3. Install required python dependencies into your python virtual environment using pip install -r requirements.txt.
4. Create the following folders in the root of the project directory: car_images, tickets.
5. python3 main.py

System Overview

The System consists of two main components –

• Vehicle detection model and
• A graphical user interface (GUI)

First, the CCTV camera footage from the roadside is sent to the system. Vehicles are detected from the footage. Tracking the activity of the vehicle’s system determines if there is any violation or not. Different types of violations have different algorithms to determine the violation. System flowchart 1 shows how the system works. The Graphical User Interface (GUI) makes the system interactive for users to use. Users can monitor the traffic footage and get an alert of violation with the captured vehicle image. Users can take further action using the GUI.

Methodology

Image Processing

1. ** Grayscaling and blurring ** As part of preprocessing the input frame got from the CCTV footage, the image is grayscaled and blurred with the Gaussian Blur method.
2. ** Background Subtraction ** Background subtraction method is used to subtract the current frame from the reference frame to get the desired object’s area. equation (1) shows the method. dst(I) = saturate(|scr1(I) − scr2(I)|)
3. ** Binary Threshold ** Binarization method is used to remove all the holes and noises from the frame and get the desired object area accurately. equation (2) shows how the binary threshold works. dst(x, y) = maxVal if scr(x, y) > thresh else 0
4. ** Dilation and find the contour ** After getting the thresholded image, it is dilated to fill the holes, and the contour is found in the image. drawing rectangle boxes over the contours desired moving objects are taken.

Vehicle Classification

From the preprocessed image moving objects are extracted. A vehicle classification model is used to classify those moving objects into three classes – Car, Motobike, and Non-vehicle. The classifier model is built with mobilenet v1 neural network architecture.

Fig: MobileNet Body Architecture.

Fig-2: Training hyperparameters.

The transfer learning approach is used to train the model with our dataset. The dataset consists of 500 images per class. The training parameters are mentioned in table (2).

Violation detection

After detecting the vehicles three violation cases arise-

• Signal violation: if a vehicle crosses a predefined line on the road while there is a red signal, it is detected as a signal violation.
• Parking violation: if a vehicle stands still in no parking zone for a predefined time, it is detected as a parking violation.
• Direction violation: when a vehicle comes from the wrong direction, it is detected by tracking the vehicle. The direction of the vehicle is determined using its current position and previous few positions.

Database Structure

We have used SQLite database with python to manage the whole data of our application. Here, in the relational database, we have used BCNF of 5 tables. The tables are:

1. Cars
2. Rules
3. Cameras
4. Violations
5. Groups

** Here are the descriptions of each table: **

Cars:

This table will hold the recorded cars by the camera. A car entity is a car with a unique identifier(id), color(color), license number of the car(license), where the car is first sighted (first_sighted), an image of the license number (license_image), an image of the car(car_image), number of rules broken so far(num_rules_broken) and the owner of the car (owner).

Rules:

This table holds all the rules, their description(name), and the fine for breaking those rules (fine).

Camera:

The camera table holds a unique identifier for the camera(id), location description(location), longitude(coordinate_x), and the latitude(coordinate_y) of the location of the camera, where the camera will feed its data video(feed) and in which group the camera is in(group).

Camera_group:

This table simply holds the unique group names of the camera groups(name). Violations: This table takes all the ids of other tables as foreign keys and creates a semantic record like this: A car with this id has broken that rule at this time, which is captured by this camera.

Implementation

Image Processing and Computer Vision

OpenCV computer vision library is used in Python for image processing purposes. For implementing the vehicle classifier, the Tensorflow machine learning framework is used.

Graphical User Interface (GUI)

The user interface has all the options needed for administration and other debugging purposes so that, we do not need to edit code for any management. For example, if we need to add some sample cars or cameras to the database, we can do it with the menu item (see fig-3).

Figure 2: Overall user interface view

Primarily, for the start of the project usage, the administrator needs to add a camera with the menu item. In this way, the administrator can add the location of the camera, and the feed file for the camera. Here the feed file is installed by the camera module over the internet. We have used a Linux file-sharing pattern for getting the video from the camera, where the camera will feed the given file to the server, and the server will take the feed file to process and detect violations. Also, the X and Y coordinate(fig-3) of the camera location can be saved by the admin. This is done for future use when we will try to use a map for locating the cameras with ease. Also, the admin needs to specify some rules with a JSON file for the camera. For example, the camera is used for crossing roads on red line violations or is used for wrong place parking detection, etc.

Figure 3: Interface for adding camera entity

Actually, this is all mainly needed for starting up the system. After adding the camera, the software will automatically start detecting violations of traffic rules. After this, opening the camera by selecting it with the drop-down menu, will fill the detection rules violations(fig-4).

Figure 4: A list view of violation records

The user has many other objects to insert into the database. The admin can add the following entities in the graphical user interface:

1. Camera (fig-3)
2. Car (fig-5)
3. Rule (fig-5)
4. Violation (fig-5)

Figure 5: Adding items interface

The GUI is made mainly for this purpose, there will always be a supervisor for a group of cameras. He can see the list of rule violations and can see details of the cars that violated the rules (fig-8). If he clicks on the detail button, a new window will appear where the user will be able to file the report or send/print a ticket for the car owner.

Figure 8: Details of rule violation

Also, the admin/user can delete the records if he gets a false positive. But there will never be a record deleted. The database has a marker of which files have been archived. If we want to retrieve a record from the deleted one, then the admin needs to go to the archive window. There he can restore any record he wants. The user can also search for a vehicle, with its license number, its color, or the date of a rule violation. The license number has text prediction so the user will be sure while typing a license number that it exists.

Figure 9: Searching for a car or rule violation

Rules violation video representation in UI

There are currently 3 rules we are concerned with.

1. Signal Violation
2. Parking Violation
3. Direction Violation.

For Signal Violation, We have used a straight line in the picture. When the traffic light is red and a car is crossing a straight line, a picture of that car is registered in the database along with some environmental values. The user can see in the live preview which cars are being detected in real-time and tested if they are crossing the line.

Figure 11: Signal violation camera representation

For Parking violations, we have prefigured a rectangle, which is the restricted area for car parking. If there is a vehicle in the rectangle for more than a predefined time, then an image with other environmental values is registered to the database.

Figure 12: Parking violation camera representation

For direction violation detection, some lines are drawn to divide into regions. Then when a car moves from one region to another, its direction is measured. If the direction is wrong, then it is registered as previous.

Figure 13: Direction violation camera representation

Libraries used for the graphical user interface:

1. PyQt5
2. QDarkStyle
3. PyQtTimer

Contributing

The main reason to publish something open source is that anyone can just jump in and start contributing to my project. So If you’d like to contribute, please fork the repository and use a feature branch. Pull requests are warmly welcome.

Links and References

• Project homepage: https://github.com/sakibreza/Traffic-Rules-Violation-Detection-System
• Repository: https://github.com/sakibreza/Traffic-Rules-Violation-Detection-System.git
• Issue tracker: https://github.com/sakibreza/Traffic-Rules-Violation-Detection-System/issues
• G. Ou, Y. Gao and Y. Liu, “Real TimeVehicularTrafficViolationDetectioninTrafficMonitorin gStream,” in 2012 IEEE/WIC/ACM , Beijing, China , 2012.
• X. Wang, L.-M. Meng, B. Zhang, J. Lu and K.-L.Du, “A Video-based Traffic Violation Detection System,” in MEC, Shenyang, China, 2013.
• PyQt: https://riverbankcomputing.com/software/pyqt/intro
• OpenCV: https://docs.opencv.org/2.4/index.html
• imutils: https://github.com/jrosebr1/imutils
• In case of any help you may need from me, please contact sakibreza@gmail.com directly without any hesitation! I will be glad to help you.

Author

Sakib Reza, Rahat Zaman
sakibreza1@gmail.com
Student at the Department of Computer Science and Engineering
Khulna University of Engineering & Technology, Khulna
Bangladesh

Supervised under
Dr. Sk. Mohammad Masudul Ahsan
Professor
Dept. of Computer Science and Engineering
Khulna University of Engineering & Technology

Licensing

The code in this project is licensed under GNU GPLv3 license.
